WHY UPGRADE YOUR SUSPENSION?

From the factory, most new 4WD vehicles are tuned for comfort during on road driving. Once weight is added in the form of accessories, passengers and cargo, performance and reliability suffer, especially when road conditions deteriorate.

Old Man Emu provide quality, application specific aftermarket suspension that is designed to increase load carrying capability and improve both vehicle handling and comfort across all terrains. A range of options provides increased ground clearance to better tackle more challenging terrain, and unlike some other accessories, you’ll notice the benefits of a new suspension system every time you drive your vehicle.



WHY OLD MAN EMU?

Suspension systems, especially when referring to 4WDs, are extremely complex. Determining the right solution for each 4WD requires special attention to many factors, with weight being the most critical. Old Man Emu 4×4 suspension by ARB approaches this in a unique way.

Instead of offering a compilation of parts that have been chosen primarily to increase the vehicle’s ride height, OME 4×4 suspension provides a range

of tuned, matched and integrated systems, each offering optimum levels of comfort, load carrying capability and control characteristics.

The complete Old Man Emu suspension range incorporates more than just 4×4 shock absorbers and springs. At ARB, we take integration to the highest level with our own selection of bushes, U bolts, centre bolts, spring liners, trim packers and suspension fitting kits.

ARBPath1205_158

NISSAN PATHFINDER SUSPENSION

The Nissan Pathfinder is a medium sized passenger wagon with a good blend of comfort for long distance touring and towing capability. Featuring an all independent suspension setup, our OME engineers focussed on increasing control and handling, particularly with extra loads on board, as well as providing modest increases in ride height.

The main limiting factor when increasing front ride height is the front upper control arm, which contacts the coil tower if downward travel is over extended. With this limit in mind, and to maintain the correct level of droop, ride height increases of approximately 30mm were achieved without costly modifications or sacrificing ride quality and safety by reducing down travel.

Multiple front springs and shocks were developed to cater for differing vehicle setups and extensive shock tuning was undertaken to optimise comfort, control and handling.

Working within the limitations of the factory independent suspension design, OME engineers have also developed a range of rear springs, providing approximately 30mm of increase in ride height and catering for a variety of load carrying requirements whilst maintaining the original vehicle rake.
